TECHNOTRANS Fountain Solution Filter System replacement for Technotrans Baldwin refrigeration and recirculation unit

TECHNOTRANS Fountain Solution Filter System replacement for Technotrans Baldwin refrigeration and recirculation unit

FFP-1000A TECHNOTRANS Fountain Solution Filter System replacement is designed for Technotrans, Baldwin, Royse dampening refrigeration and recirculation unit in KBA, ROLAND, KOMORI, SOLNA, MITSUBISHI, AKIYAMA, SAKURAI,etc sheet fed offset printing press.

It uses 3 stage filter system, UV lamp and PLC control system to efficiently filter the waste ink, particle and contaminants that affect the quality of the printing job, to disinfect the fountain solution, to display the pressure and track the fault of the filtration system.

Using FFP-1000A Fountain Solution Filter System, we can improve the stability of fountain solution for consistent print quality and prolong the life of the fountain solution and reduce the cost of printing. It is friendly to the environment so it is really green printing.

Practical Benefits:

1.Fountain Solution with more stable PH level and conductivity to keep the Fountain Solution clean and maintain high-quality printing and maximize production.

2.Reduced consumption of IPA and low production costs

3.Reduced consumption of fountain solution additives (leading to substantially longer fountain-solution service life)

4.Clean fountain solution and lower Fountain Solution disposal costs

5.Less time required to clean the Refrigeration and recirculation Dampening Cooling System and reduce press maintenance

6.The filters can be replaced independently when Refrigeration and Circulator Dampening Cooling System is running

7.Higher productivity of the printing machine

8.Environment friendly and really green printing

Specification:

CAPACITY: 1000 L/H

POWER SUPPLY:SINGLE PHRASE, 220±10% 50/60Hz 500W

UV LAMP:18W AC220V 50/60Hz

UV LIGHT WAVE LENGTH:253.7 nm

POWER FOR PUMP:370 W

TEMPERATURE RANGE:5-40 DEGREE

MAX. PRESSURE: 43.5 Psi

DIMENSION: 870X570X1250 MM

NET WEIGHT: 110 KG

GROSS WEIGHT: 140KG

Configuration

• Stainless steel filtration net of inlet

• Bubble deduct net of outlet

• Stainless steel PRE-Filtration

• Stainless steel water pump

• Fine filtration

• UV Lamp

• Intelligent contorl and display

• Fine pressure measurement

• Automatic vent valve

• Filter (5 pcs +7pcs )

• Fuse (2 pcs spare part)

• Adapter(optional)

Feature:

• FFP-1000A TECHNOTRANS loop.40 Fountain Solution Filter System replacement is designed for KBA, ROLAND, KOMORI, SOLNA, MITSUBISHI, AKIYAMA, SAKURAI, etc sheet fed offset printing press.

• Adapter is suitable for all power supply.

• It is fine filtration to remove the impurity and keep the high printing quality.

• UV lamp can disinfect the fountain solution.

• Don’t change the water and don’t drain the water. It is friendly to the environment

• Intelligent pressure measurement, control and display.

Used for
